Technical Data
|
Operating Temperature Range
|
-40 to 230 °F
|
|
Arc Suppression (TVS)
|
Included
|
|
Power Consumption (cold) - at rated voltage
|
25 Watts
|
|
Maximum Ambient Temperature
|
122 °F
|
|
Resistance at 20º C
|
1686 ohms ±10%
|
|
Voltage/Frequency
|
230 VAC 50/60 Hz
|
|
Operating Voltage Range
|
+10%/-15%
|
|
Duty Cycle Rating
|
100 %
|
|
Connector
|
ISO4400 - EN/DIN175301-803, Form A (ISO/DIN 43650) 3-pin
|
|
Solenoid Tube Diameter
|
.62 in.
|
|
Coil Nut Torque
|
4.5 lbf in.
|
|
Model Weight
|
0.60 lb.
|
|
